Delicate Anterior Treatments with Non-Prep Veneers Made of Hybrid Ceramic
Manual layering of non-prep veneers on refractory dies is a time-consuming, as well as a technology- and cost-intensive method of fabrication. Until now, it has been virtually impossible to fabricate these delicate restorations using CAD/CAM, due to the brittleness of ceramic materials. With wall thicknesses of only 0.2 mm, all-ceramic CAD/CAM materials often have chipped edges after the grinding process. In the following report, dentists Dr. Ting-Huan Lai and Dr. Cheng-Han Li, and dental technician Sharon Chou, show how the dual ceramic-polymer network structure of VITA ENAMIC (VITA Zahnfabrik, Bad Säckingen, Germany) allow non-prep veneers with the wall thicknesses of a contact lens to be technically created with CAD/CAM.
1. Diastema in the lower jaw
A 28-year-old patient came to the practice because he was dissatisfied with the esthetic appearance of his lower anterior teeth. The clinical examination showed a pronounced diastema between his middle anterior teeth. The patient refused orthodontic treatment due to the time and cost involved. The preparation and loss of healthy tooth substance were out of the question for him. The manual fabrication of non-prep veneers on refractory dies proved to be too expensive for the young patient as well. For this reason, economical and time-efficient CAD/CAM supported fabrication of the delicate veneers from the hybrid ceramic VITA ENAMIC was chosen.
2. Tooth shade determination and CAD
Before the optical scan, the tooth shade was determined with the VITA Toothguide 3D-MASTER (VITA Zahnfabrik, Bad Säckingen, Germany). The tooth shade 1M1 was determined for the two central incisors, and the corresponding VITA ENAMIC blank was selected. For the optical scan with the CEREC Omnicam (Dentsply Sirona, Bensheim, Germany), a tooth cleaning was performed, the cervical areas of 31 and 41 were made detectable with retraction threads and scan powder was applied. The non-prep veneers were then designed using the CEREC Premium 4.5.1 software (Dentsply Sirona, Bensheim, Germany).
3. Wafer-thin grinding result
The hybrid ceramic VITA ENAMIC consists of a structure-sintered glass-ceramic matrix (86 % by weight), which is then infiltrated with a polymer (14% by weight). The polymer network makes the hybrid ceramic elastic, enabling reconstructions to be made with very thin walls that also exhibit high edge stability. The hybrid ceramic blank was processed with the CEREC MC XL grinding unit (Dentsply Sirona, Bensheim, Germany) until extremely delicate microveneers with wall thicknesses of 0.2 mm were produced. Traditional CAD/CAM ceramics with such low wall thicknesses often have chipped edges after the CAM process, as they are highly brittle. In the next step, the hybrid ceramic veneers were separated from the attachment with a fine diamond.
4. Integration and final result
The try-in showed the outstanding chameleon effect of the wafer-thin restorations. Thanks to the dominant ceramic content of the hybrid ceramic, the veneers could be etched with hydrofluoric acid and silanized. Sandblasting, as is necessary with CAD/CAM composites, would have most likely destroyed such a delicate restoration. After renewed thread placement on 31 and 41 and phosphoric acid etching, the two microveneers could be successively attached in a fully adhesive manner. After final removal of the composite cement residues and careful polishing with the VITA ENAMIC Polishing Set, a highly esthetic result was achieved that was minimally invasive and efficient.
Report 11/18
Dr. Ting-Huan Lai, Dr. Cheng-Han Li, DT Sharon Chou
CEREC Asia, Taipei, Taiwan
Fig. 1: The initial situation with a pronounced diastema between the two middle anterior teeth of the lower jaw.
Fig. 2: The tooth shade determination with the VITA Toothguide 3D-MASTER covered the tooth shade range and made it possible to select a suitable block.
Fig. 3: Before the intraoral scan, retraction threads were placed to make the cervical area detectable as well.
Fig. 4: The design of the non-prep veneers in the CEREC Premium 4.4.4 software.
Fig. 5: The wafer-thin microveneer proved to have absolutely stable edges after the grinding process.
Fig. 6: The clinical try-in showed the pronounced chameleon effect of the hybrid ceramic material.
Fig. 7: The two microveneers blended invisibly into the natural row of teeth.
Fig. 8: Result: The efficient digital workflow with the hybrid ceramic VITA ENAMIC has led to a highly esthetic cosmetic result.
